ASTM A653 Stucco Wire Mesh 27*96 Inch Self Furring Expanded Metal
Lath
Product Description
This lath is produced with ASTM A 653 standard specification for
steel sheet, zinc coated or zinc iron alloy coated by hot dip
process .Diamond metal lath is a versatile metal lath ideal as a
plaster base and reinforcement for all type of walls ,ceilings and
fireproofing of steel beams and columns.
Product Specification
1.75lbs 2.5lbs 3.4lbs expanded retaining dry walls plaster stucco
galvanized mesh for formwork |
Material | Galvanized sheet G30 G60 G90,Stainless steel |
Type | Flat,self furring,dimples,"V" ribs |
Size | 27"*96" |
Weight:sq/yd | 1.75lbs 2.0lbs 2.5lbs 3.4lbs |
Package | 10 sheets/bundle,500 sheets/pallets |
Other products | Angle beads,rib lath,coil mesh, diamond metal lath,expanded metal
mesh,plaster bead, control joint beads |
Quantity for one container | 12000pcs or 10000pcs |
Product features:
1. 1.75lbs / 2.5lbs / 3.4lbs per sheet
2. Interior and exterior applications
3. Used as a renforcement for a base coat
4. Easily cut and formed for curved surfaces
5. Resists mold, fire and insect damage
6. Flexibility:readily shaped to ornamental degree not possible
with other plaster bases.
7. Security: metal lath and plaster surfaces are extremely
difficult to penetrate,provide excellent protection against
penetration or forced entry.
Product application:
The difference between flat diamond metal lath,self furring
dimpled,self furring grooved lath
1.Flat diamond metal lath
Diamond metal lath is a versatile base for cement plaster walls.it
is carefully formed diamond keys allow for proper embedment and
keying of scrated coat on all types of walls. Can be used with hand
and machine applied plaster.
2.Self furring dimpled metal lath
Self furred diamond metal lath "dimpled" is manufactured with a
1/4" dimples in the lath.The dimples provide the necessary 1/4‘
furring off the sheathing's surface to allow for proper embedment
and keying of the scrated coat on all types of walls.
3.Self furring grooved metal lath
Self-furring groove diamond metal lath is manufactuered with
approximately 1/4" deep grooves and 5 grooves per sheet to ensure
throught plaster penetration and strong mechanical bond.
Product Package:
Material | Weight | Width | Length | Packing |
G60 G90galvanized sheet | 1.75lbs | 27" | 96" | 10pcs per bundle, 50bundle per pallet |
2.5lbs | 27" | 96' | 10pcs per bundle, 50bundle per pallet |
3.4lbs | 27" | 96" | 10pcs per bundle, 50bundle per pallets |
