2.5lbs self-furring dimples galvanized 2.5lbs expanded metal lath
2.5lbs expanded metal lath basic information
This lath is produced with ASTM A 653 standard specification for
steel sheet, zinc coated or zinc iron alloy coated by hot dip
process .Diamond metal lath is a versatile metal lath ideal as a
plaster base and reinforcement for all type of walls ,ceilings and
fireproofing of steel beams and columns.
2.5lbs expanded metal lath features
1. 1.75lbs / 2.5lbs / 3.4lbs per sheet
2. Interior and exterior applications
3. Used as a renforcement for a base coat
4. Easily cut and formed for curved surfaces
5. Resists mold,fire and insect damage
6. Flexibility:readily shaped to ornamental degree not possible
with other plaster bases.
7. Security: metal lath and plaster surfaces are extremely
difficult to penetrate,provide excellent protection against
penetration or forced entry.
2.5lbs expanded metal lath detail specification
| Type | Size | Material | Production (30 days) |
| 1.75lbs | 27"*96" | Hot dip galvanized | 30000pcs |
| 2.5lbs | 27"*96" | Hot dip galvanized | 30000pcs |
| 3.4lbs | 27"*96" | Hot dip galvanized | 30000pcs |
The difference between flat diamond metal lath,self furring
dimpled,self furring grooved lath
1.Flat diamond metal lath
Diamond metal lath is a versatile base for cement plaster walls.it
is carefully formed diamond keys allow for proper embedment and
keying of scrated coat on all types of walls. Can be used with hand
and machine applied plaster.
2.Self furring dimpled metal lath
Self furred diamond metal lath "dimpled" is manufactured with a
1/4" dimples in the lath.The dimples provide the necessary 1/4‘
furring off the sheathing's surface to allow for proper embedment
and keying of the scrated coat on all types of walls.
3.Self furring grooved metal lath
Self-furring groove diamond metal lath is manufactuered with
approximately 1/4" deep grooves and 5 grooves per sheet to ensure
throught plaster penetration and strong mechanical bond.
